Product Overview
Technical Specifications
| Model | TT-L1 AI Pro |
|---|---|
| Application | In-lift biometric floor access |
| Verification | Dynamic face, fingerprint, card, password; combination verification |
| Display | 5-inch IPS touchscreen; 1280 x 720 |
| CPU / NPU | 1.2GHz dual-core ARM Cortex-A7 / 0.6 TOPS |
| Memory / Storage | 256MB DDR3L / 4GB eMMC |
| Operating System | Linux 3.10 |
| User Capacity | 15,000 |
| Face Capacity | 5,000 |
| Fingerprint Capacity | 10,000 |
| Card Capacity | 15,000 |
| Card Frequency | 125kHz standard; 13.56MHz optional |
| Password Capacity | 15,000 |
| Log Capacity | 500,000 verification logs |
| Face Verification Time | Less than 0.2 seconds |
| Recognition Distance | 0.5–2.5m; 0.5–1.5m with live detection |
| Live Detection | Dual-camera anti-spoofing |
| Cameras | 2MP WDR colour + 2MP infrared; 75° FOV |
| Communication | TCP/IP, WiFi, USB Type-A |
| Lift Controller Interface | RS485 to TT-LC16 |
| Power Supply | DC 12V 2A |
| Operating Temperature | -15–60°C |
| Dimensions | 180 x 180 x 26mm |
Product Catalogue
Preview the product catalogue here or open it in a new tab.
Product Video
Watch the product demonstration and key functions directly here.
- AI face recognition
- Attendance verification
- Door access ready
- WiFi / TCP-IP connectivity
